Chrysler A518 transmission

A518

Also known as 46RH (A518); 47RH (A618); 46RE (A518 electronic governor); 47RE (A618 electronic governor) Versions of this transmission were used from 1990-up. An electronic governor was introduced in 1997. There were MANY variations over the years and MANY parts do NOT interchange from year to year or model to model. DO NOT confuse it with the three speed A727 which uses the same pan gasket.

Rear cooler line is the cooler return line.

Band adjustments:
Intermediate = 2½ turns
Reverse = 2 turns

Gear Ratios:
2.45:1 1st gear
1.45:1 2nd gear
1.00:1 3rd gear
0.69:1 4th gear
2.21:1 reverse
